1. Screw in the lifting eyes (eyebolts) depending on the position of the motor
during transport.
① Position of the eyebolts
2. Hook the crossbar into the eyebolts (lifting eyes).
Figure 4-2 Transporting the motor with a beam (example)
Preparing for use
4.2 Transportation and storage
SIMOTICS S-1FK2 synchronous motors for SINAMICS S120
54 Operating Instructions, 02/2022, A5E46089564B AD
