Siemens SIMOTION D410-2DP/PN

Meaning Display priority
1)
RDY RUN/STOP OUT>5V
OUT>5V/SY
2)
SF/BF:
DCP flashing (for interface X150,
X127)
This function is used to check the
correct assignment to a module
and its interfaces.
DCP flashing of the module is acti‐
vated in HW Config under "Target
system" > "Ethernet" > "Edit Ether‐
net node" > Button "Browse" >
"Flashing" button
3 x x x 2/1
(green)
PROFIBUS DP interface bus error
●
PROFIBUS master: At least 1
slave is missing
● PROFIBUS slave: No
parameter assignment master
available
4 x x x 2/1
(red)
Communication error PROFINET
7)
4 x x x 2/1
(red)
An interrupt that can be acknowl‐
edged (alarm, message, note) is
pending
5 x x x 1
(red)
Underlicensing of
technology/option objects
6 x x x 0.5/1
(red)
SIMOTION ready for operation 6 x Static/flashing
(green or yel‐
low)
x x
RUN 6 x 1
(green)
x x
Transition from STOP/STOPU to
RUN
6 x 2/1
(green)
x x
STOP/STOPU 6 x 1
(yellow)
x x
Transition
●
from RUN to STOP/STOPU
● STOP to STOPU
● STOPU to STOP
6 x 2/1
(yellow)
x x
Service operating state
(axis control panel in the STOPU/
measuring function)
5 x 2/1
(yellow/green)
x x
General reset requested by SIMO‐
TION D410‑2 or with the mode
switch
5 x 0,5/1
(yellow)
x x
Memory reset in progress 5 x 0 x 0
Memory reset stopped (STOP) 6 x 1
(yellow)
x x
States of the SINAMICS Integrated (LED RDY)
Diagnostics
9.1 Diagnostics via LED displays
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 299
