4. The converter is controlled exclusively via the digital inputs/outputs or analog inputs/outputs on the optional
TM31 customer interface.
Terminal block on the CU320-2 Control Unit
-X122 Factory setting Comment
DI0 Not assigned
DI1 Not assigned
DI2 Not assigned
DI3 Not assigned
DI16 Not assigned
DI17 Not assigned
M1
M (GND)
DI/DO8 Not assigned Factory-set as output
DI/DO9 Not assigned Factory-set as output
M (GND)
DI/DO10 Not assigned Factory-set as output
DI/DO11 Not assigned Factory-set as output
M (GND)
-X132
DI4 Not assigned
DI5 Not assigned
DI6 Not assigned
DI7 Not assigned
DI20 Not assigned
DI21 Not assigned
M2
M (GND)
DI/DO12 Error message acknowledgement, Braking
Module
Output is used (reserved) in conjunction with the Braking
Module
DI/DO13 Not assigned Factory-set as output
M (GND)
DI/DO14 Not assigned Factory-set as output
DI/DO15 Not assigned Factory-set as output
M (GND)
The factory settings of the bidirectional inputs/outputs are underscored.
Terminal block on the TM31 Terminal Module
Factory setting Comment
-X520 Optocoupler inputs with common potential
DI0 ON/OFF 1
DI1 Increase setpoint/fixed setpoint 0 Parameters can be set in the firmware to determine whether
operation is via motorized digital potentiometer or fixed
setpoint
DI2 Decrease setpoint/fixed setpoint 1
DI3 Acknowledge fault
-X530 Optocoupler inputs with common potential
DI4 OFF 2
1)
Immediate pulse disable, motor coasts to standstill
DI5 OFF 3
1)
Ramp-down along quick-stop ramp, only of relevance in
conjunction with the Braking Module
DI6 External fault
1)
DI7
1)
A jumper must be inserted here if these inputs are not used
