SINAMICS S120 Cabinet Modules
Engineering Information
SINAMICS Engineering Manual – November 2015
Ó Siemens AG
447/528
Power requirement of supplementary components
The following components are connected in each case in the installed S120 Cabinet Modules downstream of the fuse
protection for the auxiliary voltage supply system. The power requirement must be added to the basic requirement of
the relevant Cabinet Module specified on the pages above.
CU320-2 Control Unit
Voltage 24 V DC (20.4 V – 28.8 V)
Maximum power requirement (at 24 V DC) without taking
account of digital outputs and expansions in the option slot
1.0 A
Maximum fuse protection 20 A
Digital inputs: 12 floating digital inputs
8 bidirectional non-floating digital outputs/digital inputs
§ Voltage -3 V to +30 V
§ Low level (an open digital input is interpreted as "low") -3 V to +5 V
§ High level +15 V to +30 V
§ Power consumption (typ. at 24 V DC) 9 mA
Digital outputs (continuously short circuit proof): 8 bidirectional non-floating digital outputs/digital inputs
§ Voltage 24 V DC
§ Maximum load current per digital output 500 mA
Terminal Module 31 (TM31)
Voltage 24 V DC (20.4 V – 28.8 V)
Maximum power requirement (at 24 V DC) without taking
account of digital outputs and DRIVE-CLiQ supply
0.2 A
Digital outputs (continuously short circuit proof): 4 bidirectional non-floating digital outputs/digital inputs
§ Voltage 24 V DC
§ Maximum load current per digital output 100 mA
Sensor Module Cabinet-Mounted 10 (SMC10)
Voltage 24 V DC (20.4 V – 28.8 V)
Maximum power requirement (at 24 V DC) not taking
encoder into account
0.2 A
Sensor Module Cabinet-Mounted 20 (SMC20)
Voltage 24 V DC (20.4 V – 28.8 V)
Maximum power requirement (at 24 V DC) not taking
encoder into account
0.2 A
Sensor Module Cabinet-Mounted 30 (SMC30)
Voltage 24 V DC (20.4 V – 28.8 V)
Maximum power requirement (at 24 V DC) not taking
encoder into account
0.2 A
Advanced Operator Panel 30 (AOP30)
Voltage 24 V DC (20.4 V – 28.8 V)
Maximum power requirement (at 24 V DC):
- Without backlit display 100 mA
- With maximum backlit display 200 mA
