Siemens SINUMERIK 802C base line User Manual

Technical Appendix
6-10 SINUMERIK 802C base line
Start-Up
34070 REFP_VELO_POS
mm/min,
rev/min
Reference point positioning velocity RESET
_always 1000.0 0.0 plus DOUBLE 2/7
34080 REFP_MOVE_DIST
mm,
deg.
Reference point distance/target point for distance–coded
system
RESET
_always –2.0 – – DOUBLE 2/7
34090 REFP_MOVE_DIST_CORR
mm,
deg.
Reference point offset/absolute offset distance–coded POWER ON
_always 0.0 – – DOUBLE 2/7
34092 REFP_CAM_SHIFT
mm,
deg.
Electr. cam offset of incremental measuring systems with
equidistant zero marks
RESET
_always 0.0 0.0 plus DOUBLE 2/7
34100 REFP_SET_POS
mm,
deg.
Reference point value/irrelevant for distance–coded
system: 0 ... 3
RESET
_always 0., 0., 0., 0. – – DOUBLE 2/7
34110 REFP_CYCLE_NR
– Sequence of axes in channel–specific referencing
–1: No obligatory reference point for NC Start
0: No channel–specific reference–point approach
1–15: Sequence in channel–specific reference point
approach
RESET
_always 1 –1 31 DWORD 2/7
34200 ENC_REFP_MODE
– Type of position measuring system
0: No ref. point appr.; if an absolute encoder exists:
REFP_SET_POS accepted
1: Zero pulse (on encoder track)
POWER ON
_always 1 0 6 BYTE 2/7
35010 GEAR_STEP_CHANGE_ENABLE
– Gear change possible. Spindle has several gear steps POWER ON
_always 0 *** ***
BOOLEAN
2/7
35040 SPIND_ACTIVE_AFTER_RESET
– Own spindle reset POWER ON
_always 0 *** ***
BOOLEAN
2/7
35100 SPIND_VELO_LIMIT
rev/min Maximum spindle speed POWER ON
_always 10000 0.0 plus DOUBLE 2/7
