Siemens SINUMERIK 802C base line User Manual

Technical Appendix
SINUMERIK 802C base line
6-11
Start-Up
35110 GEAR_STEP_MAX_VELO
rev/min Maximum speed for gear change (gear stage no.): 0..5 NEW CONF
_always 500, 500, 1000,
2000, 4000, 8000
0.0 plus DOUBLE 2/7
35120 GEAR_STEP_MIN_VELO
rev/min Minimum speed for gear change (gear stage no.): 0..5 NEW CONF
_always 50, 50, 400, 800,
1500, 3000
0.0 plus DOUBLE 2/7
35130 GEAR_STEP_MAX_VELO_LIMIT
rev/min Maximum speed of gear stage (gear stage no.): 0...5 NEW CONF
_always 500, 500, 1000, 2000,
4000, 8000
0.0 plus DOUBLE 2/7
35140 GEAR_STEP_MIN_VELO_LIMIT
rev/min Minimum speed of gearsetp (gear stage no.): 0...5 NEW CONF
_always 5, 5,10, 20, 40, 80 0.0 plus DOUBLE 2/7
35150 SPIND_DES_VELO_TOL
Factor Spindle speed tolerance RESET
_always 0.1 0.0 1.0 DOUBLE 2/7
35160 SPIND_EXTERN_VELO_LIMIT
rev/min Spindle speed limitation from PLC NEW CONF
_always 1000 0.0 plus DOUBLE 2/7
35200 GEAR_STEP_SPEEDCTRL_ACCEL
rev/s^2 Acceleration in speed control mode [gear stage no.]: 0...5 NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE 2/7
35210 GEAR_STEP_POSCTRL_ACCEL
rev/s^2 Acceleration in position control mode (gear stage no.):
1...5
NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE 2/7
35220 ACCEL_REDUCTION_SPEED_POINT
Factor Speed for reduced acceleration RESET
_always 1.0 0.0 1.0 DOUBLE 2/7
35230 ACCEL_REDUCTION_FACTOR
Factor Reduced acceleration RESET
_always 0.0 0.0 0.95 DOUBLE 2/7
35240 ACCEL_TYPE_DRIVE
– Type of acceleration RESET
001
BOOLEAN
2/7
