Siemens SINUMERIK 808D ADVANCED Parameter Manual

20194 IGNORE_NONCSTART_ASUP EXP K1
- Permit ASUB in spite of "Interlock NC-START" if user alarms
present.
DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 2/2 M
Description: If a user alarm is present from the number range 65500-65999, an ASUB start from reset
is permitted in
spite of the response "Interlock NC-START", which has these alarms. An
ASUB start from an active or stopped state is not influenced by this.
Bit 0 is assigned to interrupt 1.
Bit 1 is assigned to 2, etc.
Corresponds with:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
20201 CHFRND_MODE_MASK C09 V1
- Chamfer/rounding behavior DWORD Reset
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0xFFFF 1/1 M
Description: Determination of the chamfer/rounding behavior
Bit 0: (LSB) Assignment of the chamfer/rounding to the preceding or following block.
This influences:
● The technology of the chamfer/rounding (feed, type of feed, M commands ...)
● The
execution of
the blocks without movement in the active plane (e.g. M commands,
movement in the applicate) before or after a modal rounding (RNDM)
Bit 1: free
Meaning of the individual bits:
Bit 0 = 0
Chamfer/rounding is derived from the following block (default value).
The technology of the chamfer/rounding is determined by the following block. Blocks
without movement (M commands) or movement only in the applicate between two movement
blocks in the plane are executed before the modal rounding.
Bit 0 = 1:
Chamfer/rounding is derived from the preceding block.
The technology of the chamfer/rounding is determined by the preceding block. Blocks
without movement (M commands) or movement only in the applicate between two movement
blocks in the plane are executed after the modal rounding.
20202 WAB_MAXNUM_DUMMY_BLOCKS C02, C06 W1
- Maximum number of blocks w/o traversing movement with SAR BYTE Reset
-
- - 5, 5, 5, 5, 5, 5, 5, 5... 0 10 7/2 M
Description: Maximum number of blocks which can appear between the SAR (soft approach and
retraction) block and the traversing block which determines the direction of the
approach or retraction tangent.
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 137
