24220 TRAFO_GEOAX_ASSIGN_TAB_2 C07 F2, M1
- Assignment of geometry axes to channel axes for transformation
2
BYTE NEW CONF
-
808d-me42 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-me62 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-te42 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-te62 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-mte40 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 7/7 U
808d-mte60 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 7/7 U
Description: This MD states the channel axes on which the axes of the cartesian coordinate system
are mapped for active transformation 2.
Otherwise the meaning corresponds to TRAFO_GEOAX_ASSIGN_TAB_1.
24230 TRAFO_INCLUDES_TOOL_2 C07 -
- Tool handling with active 2nd transformation BOOLEAN NEW CONF
-
808d-me42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-me62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-mte40 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 7/7 U
808d-mte60 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 7/7 U
Description: This machine data states for each channel whether the tool is handled during the 2nd
transformation or externally.
This machine data is evaluated only with specific transformations.
It is evaluated on the condition that the orientation of the tool with reference to
the Basic Coordinate System cannot be changed by the transformation. In standard
transformations, only "inclined-axis transformation" fulfills this condition.
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 185
