Special cases, errors, ... When the axes have been stopped with IS "Delete distance-to-go" the next
program block is prepared with the new positions. After a "Delete distance-
to-go", geometry axes thus follow a different contour to the one originally
defined in the part program.
If G90 is programmed in the block after "Delete distance-to-go" it is at least
possible to approach
the programmed absolute position. On the other hand,
with G91, the position originally defined in the part program is not reached in
the following block.
corresponding to ... DB380x DBX2.2 (Distance-to-go / Spindle reset)
Note for the reader Function Manual Basic Functions K1
DB3200
DBX6.4
Program level abort
Signal(s) to channel (PLC → NCK)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
At each edge change 0 → 1 the actual program level being processed (sub‐
program level) is immediately aborted. Processing of the part program con‐
tinues at the next higher program level from the exit point.
Signal state 0 or edge
change 1 → 0
No effect
Special cases, errors, ... The main program level cannot be interrupted with the IS, but only with the
IS "Reset".
Note for the reader Function Manual Basic Functions K1
DB3200
DBX6.6
Rapid traverse override active
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The rapid traverse override between 0 and a maximum of 100% entered in
the PLC interface is channel-specific.
Signal state 0 or edge
change 1 → 0
The rapid traverse override entered at the PLC interface is ignored.
When the rapid traverse override is inactive, the NC always uses 100% as
the internal override factor.
Note:
The 1st switch position of the gray-coded interface for the value is an excep‐
tion. Also here for "Rapid traverse override inactive", this override factor is
used and for axes, 0% is output as override value.
Special cases, er‐
rors, ...
The rapid traverse override is inactive when G33 is active.
corresponding to ... IS "Rapid traverse override" (DB3200 DBX5)
Note for the reader Function Manual Basic Functions V1
DB3200
DBX6.7
Feedrate override active
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.7 Channel-specific signals
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 383
