Signal state 1 or edge
change 0 → 1
The feedrate override between 0 and a maximum of 120% entered at the PLC
interface is active for the path feedrate and therefore automatically for the
related axes.
In JOG mode, the feedrate override acts directly on the axes.
Signal state 0 or edge
change 1 → 0
The feedrate override entered at the PLC interface is ignored.
When the feedrate override is inactive, the NC always uses 100% as the
internal override factor.
Note:
The 1st switch position of the gray-coded interface for the value is an excep‐
tion. Also here, for "Feedrate override inactive", this override factor is used
and for axes, 0% is output as override value (acts the same as "feedrate
disable").
Special cases, er‐
rors, ...
The feedrate override is inactive when G33 is active.
corresponding to ... IS "Feedrate override" (DB3200 DBX4)
Note for the reader Function Manual Basic Functions V1
DB3200
DBX7.0
NC start disable
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
IS "NC start" is inactive.
Signal state 0 or edge
change 1 → 0
IS "NC start" is active.
Application This signal is used to suppress renewed program execution because, for
example, there is no lubricant.
corresponding to ... IS "NC start"
Note for the reader Function Manual Basic Functions K1
DB3200
DBX7.1
NC start
Signal(s) to channel (PLC → NCK)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
AUTOMATIC mode: The selected NC program is started or continued.
If
data is
transferred from the PLC to the NC during program status "Program
interrupted," then this data is immediately processed with NC start.
MDI mode: The part program blocks that were entered are enabled for exe‐
cution or are continued.
Signal state 0 or edge
change 1 → 0
No effect
corresponding to ... IS "NC start disable"
Note for the reader Function Manual Basic Functions K1
DB3200
DBX7.2
NC stop at block limit
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.7 Channel-specific signals
