Machine data
2.3 Channel-specific machine data
Parameter Manual
102
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Parameterization of the events causing the user program set with MD11620
$MN_PROG_EVENT_NAME (default: _N_PROG_EVENT_SPF) or the safety program
_N_SAFE_SPF to be called implicitly:
Bit 0 = 1 : Start of part program
Bit 1 = 1 : End of part program
Bit 2 = 1 : Operator panel reset
Bit 3 = 1 : Ramp-up
Bit 4 = 1 : Reserved
Bit 5 = 1 : Safety program booting
The user program is called via the following search path:
1. /_N_CUS_DIR/_N_PROG_EVENT_SPF
2. /_N_CMA_DIR/_N_PROG_EVENT_SPF
3. /_N_CST_DIR/_N_PROG_EVENT_SPF
The safety program has to be available in the following location:
1. /_N_CST_DIR/_N_SAFE_SPF
Furthermore, MD11450 $MN_SEARCH_RUN_MODE bit 1 also causes the user program
set with MD11620 $MN_PROG_EVENT_NAME to be started up automatically after the
action blocks, regardless of the settings in the machine data.
Corresponds to:
MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK
MD20106 $MC_PROG_EVENT_IGN_SINGLEBLOCK
MD20107 $MC_PROG_EVENT_IGN_INHIBIT
MD20192 $MC_PROG_EVENT_IGN_PROG_STATE
MD20193 $MC_PROG_EVENT_IGN_STOP
Description: Parameterization of additional properties of the event-controlled program
calls (in short, Prog-Event), that is, the MD20108 $MC_PROG_EVENT_MASK is
further parameterized.
Bit 0 = 1 :
An ASUB started from channel status RESET does not result in a Prog-Event.
20108 PROG_EVENT_MASK N01, - TE3,K1
- Setting of event-driven programm calls DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2
20109 PROG_EVENT_MASK_PROPERTIES N01 K1
- Properties of Prog-Events DWORD PowerOn
-
- - 0x01 0 0x1 2/2
