Machine data
2.3 Channel-specific machine data
Parameter Manual
142
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
This machine data defines the interpolation behavior of G0:
0: Non-linear interpolation (RTLIOF): Each path axis interpolates as an
individual axis (positioning axis), independently of the other axes, at the
rapid traverse velocity of the axis (MD32000 $MA_MAX_AX_VELO).
1: Linear interpolation (RTLION): The path axes are interpolated jointly.
Related to:
MD20732 $MC_EXTERN_G0_LINEAR_MODE
Description: This machine data defines the interpolation behavior of G00:
0: Axes are traversed as positioning axes
1: Axes interpolate with each other
Related to:
MD10886 $MN_EXTERN_INCREMENT_SYSTEM
20730 G0_LINEAR_MODE C09 P2
- G0 interpolation mode BOOLEAN PowerOn
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE...
0 - 2/2
20732 EXTERN_G0_LINEAR_MODE N12 P2
- G00 interpolation mode BOOLEAN PowerOn
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE...
0 - 7/2
