Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
163
Machine data
2.3 Channel-specific machine data
18 Recording of the processing of the Event-Queue and generation of com-
mand sequences
19 Recording of event destructor call
20 Recording of the dynamic limitations per block (only active when bit 0
is set).
21 Recording of the Look Ahead data (only active when bit 0 is set).
Both a static part as well as a block-related part with the dynamic
block data are output at the time of trace generation.
22 Config data output (static)
23 Recording if computing time is given away in the preprocessing (only
active when bit 0 is set).
Description: Definition of the unit for the scaling factor P and for the axial scaling
factors I, J, K.
Meaning:
0 Scale factor in 0.001
1 Scale factor in 0.00001
Related to:
SD43120 $SA_DEFAULT_SCALE_FACTOR_AXIS,
SD42140 $SC_DEFAULT_SCALE_FACTOR_P
Description: This MD enables axial scaling.
Meaning:
0: Axial scaling not possible
1: Axial scaling possible -> MD DEFAULT_SCALE_FACTOR_AXIS is active
Related to:
SD43120 $SA_DEFAULT_SCALE_FACTOR_AXIS
22910 WEIGHTING_FACTOR_FOR_SCALE EXP, C01, C11 -
- Input resolution for scaling factor BOOLEAN PowerOn
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 2/2
22914 AXES_SCALE_ENABLE EXP, C01, C11 -
- Activation for axial scaling factor ( G51 ) BOOLEAN PowerOn
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 2/2
