Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
165
Machine data
2.3 Channel-specific machine data
Description: Bit mask for saving and activating data handling frames.
The following applies:
Bit 0:
Data handling frames are only activated by programming the bit masks
$P_CHBFRMASK, $P_NCBFRMASK and $P_CHSFRMASK. G500..G599 only activate the
relevant settable frame. The reset behavior is independent of this.
Bit 1:
Data handling frames are not written implicitly by system functions such as
TOROT, PAROT, ext. work offset, transformations.
Description: Setting the following bits activates certain properties of the settable
frame:
Bit 0 = 0: default behavior.
Bit 0 = 1: if MD20152 $MC_GCODE_RESET_MODE[7] = 1, the last active settable
frame is selected again according to G code group 8 after power up of the
control.
24050 FRAME_SAA_MODE C03 -
- Saving and activating of data management frames DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x0000003 1/1
24080 USER_FRAME_POWERON_MASK N01 -
- Parameterize properties for settable frame DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x1 7/2
