Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
167
Machine data
2.3 Channel-specific machine data
Corresponds with:
MD24200 $MC_TRAFO_TYPE_2, MD24300 $MC_TRAFO_TYPE_3, ... MD24460
$MC_TRAFO_TYPE_8
References:
/FB/, F2, "5-Axis Transformation"
Description: Axis assignment at input point of 1st transformation
The index input at the nth position states which axis is mapped internally
from the transformation to axis n.
Not relevant:
No transformation
Releated to:
MD24200 $MC_TRAFO_TYPE_2, MD24300 $MC_TRAFO_TYPE_3, ...
MD24460 $MC_TRAFO_TYPE_8
References:
/FB/, F2, "5-Axis Transformation"
Description: This MD states the channel axes on which the axes of the cartesian coordinate
system are mapped for active transformation 1.
Not relevant:
No transformation
Related to:
MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB, if no transformation is active.
References:
/FB/, K2, "Coordinate Systems, Axis Types, Axis Configurations, Workpiece-
Related Actual Value System, External Work Offset"
24110 TRAFO_AXES_IN_1 C07 F2,TE4,M1,K1,W1
- Axis assignment for the 1st transformation in the channel BYTE NEW CONF
-
808d-me42 4 0, 0, 0, 0 0 20 1/1
808d-me62 5 0, 0, 0, 0, 0 0 20 1/1
808d-te42 4 0, 0, 0, 0 0 20 1/1
808d-te62 4 0, 0, 0, 0, 0 0 20 1/1
24120 TRAFO_GEOAX_ASSIGN_TAB_1 C07 F2,TE4,TE4,M1,K1,W1
- Assignment of the geometry axes to channel axes for
transformation 1
BYTE NEW CONF
-
- 3 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1
