Siemens SINUMERIK 808D ADVANCED

Machine data
2.1 Display machine data
Parameter Manual
20 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
This MD is used to define the number of decimal places of the position dis-
play, for linear axes in metric systems, in general for rotary axes.
Spindle positions are treated like rotary axis positions.
The position display is displayed with a max. of 10 characters including
signs and decimal places. A positive sign is not displayed.
By default 3 digits are displayed after the decimal point.
MD value=3: display resolution = 10-3 [mm] or [degree],
Related to:
MD 10200: INT_INCR_PER_MM bzw. MD 10210: INT_INCR_PER_DEG
Description: This MD is used to define the number of decimal places of the position dis-
play for linear axes in the inch system of measurement.
The position display is displayed with a max. of 10 characters including
signs and decimal places. A positive sign is not displayed.
By default 4 digits are displayed after the decimal point.
MD value=4: display resolution = 10-4 [inch]
For rotary axes and spindle positions the display is maintained as in MD 203.
Related to:
MD 10200: INT_INCR_PER_MM, MD 203: DISPLAY_RESOLUTION
Description: This MD is used to define the number of decimal places for spindle speed dis-
play.
The values are displayed with a max. of 10 characters including sign and dec-
imal point. A positive sign is not displayed.
By default 1 digit is displayed after the decimal point.
MD value=1: display resolution = 10-1
Description: Protection level of the tool offsets, general
Description: Protection level for tool offsets (geometry) for writing
203 DISPLAY_RESOLUTION --
- Display resolution for mm dimension system BYTE Immediately
-
-0 3 0 5 3/2
204 DISPLAY_RESOLUTION_INCH --
- Display resolution for inch system of measurement BYTE Immediately
-
-0 4 0 5 3/2
205 DISPLAY_RESOLUTION_SPINDLE --
- Display resolution for spindle values BYTE Immediately
-
-0 1 0 5 3/2
207 USER_CLASS_READ_TOA --
- Read tool offsets protection level, general BYTE Immediately
-
-0 7 0 7 3/3
208 USER_CLASS_WRITE_TOA_GEO --
- Write tool geometry protection level BYTE Immediately
-
-0 7 0 7 3/3
