Machine data
2.1 Display machine data
Parameter Manual
22
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Directory access protection level
Description: PLC project protection level
Description: Protected work area protection level
Description: PG: baud rate (300, 600, 1200, 2400, 4800, 9600, 19200, 38400)
Description: PLC station address
Description: NCK station address
Description: Use this MD to define the time intervals in which the simulation graphic is
updated on the current machine tool machining.
Value = 0 means no update
Description: The position of the coordinate system can be changed as follows:
221 USER_CLASS_DIR_ACCESS --
- Directory access protection level BYTE Immediately
-
-0 7 0 7 3/3
222 USER_CLASS_PLC_ACCESS --
- PLC project protection level BYTE Immediately
-
-0 7 0 7 2/2
223 USER_CLASS_WRITE_PWA --
- Protected work area protection level BYTE Immediately
-
-0 7 0 7 3/2
247 V24_PG_PC_BAUD --
- PG: baud rate (300, 600, 1200, 2400, 4800, 9600, 19200,
38400)
BYTE Immediately
-
-0 7 5 9 3/3
280 V24_PPI_ADDR_PLC --
- PLC station address BYTE PowerOn
-
- - 2 0 126 3/3
281 V24_PPI_ADDR_NCK --
- NCK station address BYTE PowerOn
-
- - 3 0 126 3/3
289 CTM_SIMULATION_TIME_NEW_POS --
- Simulation of actual value update rate BOOLEAN Immediately
-
- 0 100 0 4000 4/3
290 CTM_POS_COORDINATE_SYSTEM --
- Coordinate system position BYTE Immediately
-
-0 2 0 7 4/3
