NC setting data
Description: Value not equal to 0:
The velocity value entered applies to axes traversed in JOG mode if revolu-
tional feedrate (G95) is active for the relevant axis (SD41100
$SN_JOG_REV_IS_ACTIVE = 1). The axis velocity is active for
• continuous jogging
• incremental jogging (INC1, ... INCvar)
• handwheel traversing. The value entered is valid for all axes and must
not exceed the maximum permissible axis velocity (MD32000
$MA_MAX_AX_VELO).
Value = 0:
If 0 has been entered in the setting data, the active revolutional feedrate
in JOG mode is MD32050 $MA_JOG_REV_VELO "revolutional feedrate with JOG".
Each axis can be given its own revolutional feedrate with this MD (axial MD).
SD irrelevant for ......
• For axes if SD41100 $SN_JOG_REV_IS_ACTIVE = 0
Application example(s)
The operator can define a JOG velocity for a particular application.
Related to ....
Axial SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feedrate for JOG active)
Axial MD32050 $MA_JOG_REV_VELO (revolutional feedrate with JOG)
Axial MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
Description: Value not equal to 0:
The velocity entered applies to rotary axes in JOG mode (to continuous jog-
ging, incremental jogging, jogging with handwheel). The value entered is
common to all rotary axes, and must not exceed the maximum permissible axis
velocity (MD32000 $MA_MAX_AX_VELO).
With DRF, the velocity set with SD41130 $SN_JOG_ROT_AX_SET_VELO must be
reduced by MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR.
Value equal to 0:
If the value 0 is entered in the setting data, the velocity applied to rotary
axes in JOG mode is the axial MD32020 $MA_JOG_VELO (jog axis velocity). In
this way, it is possible to define a separate JOG velocity for each axis.
Application example(s)
The operator can define a JOG velocity for a particular application.
Related to ....
MD32020 $MA_JOG_VELO (JOG axis velocity)
MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR (ratio JOG velocity to handwheel
velocity (DRF)
41120 JOG_REV_SET_VELO -H1
mm/rev Revolutional feedrate of axes in JOG mode DOUBLE Immediately
-
-- 0.0 0.0 - 1/1
41130 JOG_ROT_AX_SET_VELO -H1
rev/min Axis velocity for rotary axes in JOG mode DOUBLE Immediately
-
-- 0.0 0.0 - 7/7
