Detailed descriptions of interface signals
4.7 Channel-specific signals
Parameter Manual
374
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
DB3300
DBX1001.0 to .6
DBX1005.0 to .6
DBX1009.0 to .6
Active machine function 1 INC, ..., continuous
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The PLC interface receives a signal stating which machine function is active
in the JOG mode for the geometry axes.
Signal state 0 The machine function in question is not active.
corresponding to ... IS "Machine function 1 INC, ..., continuous"
for axis 1 in the Work (DB3200 DBX1001.0 ... .6)
for axis 2 in the Work (DB3200 DBX1005.0 ... .6)
for axis 3 in the Work (DB3200 DBX1009.0 ... .6)
Note for the reader Function Manual Basic Functions H1
DB3300
DBX4001.1
Workpiece setpoint reached
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The specified workpiece target has been reached.
Depending on the setting in MD27880 PART_COUNTER:
Bit 1 = 0:for $AC_REQUIRED_PARTS equal to $AC_ACTUAL_PARTS
Bit 1 = 1:for $AC_REQUIRED_PARTS equal to $AC_SPECIAL_PARTS
Signal state 0 The specified workpiece target has not been reached.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX4002.0
ASUB is stopped
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The signal is set to 1 if the control stops automatically prior to the end of
ASUB (interrupt in a program mode and channel status stopped).
Signal state 0 The IS is set to 0 with start and reset.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX4002.5
Associated M01/M00 active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The IS is used to display that for a corresponding previous enable /
activation, an associated M00 or M01 auxiliary function is active.
Signal state 0 No associated M00/M01 auxiliary functions active.
corresponding to ... DB3200 DBX14.5 (activate associated M01)
Note for the reader Function Manual Basic Functions K1
DB3300
DBX4002.6
Dry run feedrate active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
