Siemens SINUMERIK 808D ADVANCED - Page 45

Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
45
Machine data
2.2 General machine data
Description: If an M function replacement was configured with MD10715
$MN_M_NO_FCT_CYCLE[n] / MD10716 $MN_M_NO_FCT_CYCLE_NAME[n], a parameter
transfer via system variable can be specified for one of these M functions
using MD10718 $MN_M_NO_FCT_CYCLE_PAR, in the same way as T function replace-
ment. The parameters stored in the system variables always refer to the part
program line where the M function to be replaced was programmed.
The following system variables are available:
$C_ME : Address extension of the replaced M function
$C_T_PROG : TRUE if address T was programmed
$C_T : Value of address T ( Integer )
$C_TE : Address extension of address T
$C_TS_PROG : TRUE if address TS was programmed
$C_TS : Value of address TS (string, only with tool management )
$C_D_PROG : TRUE if address D was programmed
$C_D : Value of address D
$C_DL_PROG : TRUE if address DL was programmed
$C_DL : Value of address DL
Description: This machine data parameterizes the execution of the replacement subprogram
for the tool and tool offset selection.
Bit 0 = 0:
D or DL number is transferred to the replacement subprogram (default value)
Bit 0 = 1:
The D or DL number is not transferred to the replacement subprogram if the
following conditions are fulfilled: MD22550 $MC_TOOL_CHANGE_MODE = 1 Pro-
gramming D/DL with T or M function with which the tool change cycle is
called, in a part program line.
Bit 1 = 0
Execution of the replacement subprogram at end of block (default value)
Bit 1 = 1
Execution of the replacement subprogram at block start
Bit 2 = 0:
Execution of the replacement subprogram according to the settin of bit 1
Bit 2 = 1:
Execution of the replacement subprogram at block start and at end of block.
10718 M_NO_FCT_CYCLE_PAR EXP, N12, N07 K1
- M function replacement with parameters DWORD PowerOn
-
- - -1 - - 2/2
10719 T_NO_FCT_CYCLE_MODE EXP, N12, N07 K1
- Setting of T function substitution DWORD PowerOn
-
-- 0 0 7 2/2
