Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
69
Machine data
2.2 General machine data
Description: This bit mask can be used to set the behavior of the control during reposi-
tioning.
Bit no. Meaning when bit set
----------------------------------------------------------------------------
-
0 (LSB)
The dwell time is continued in the residual block from where it was inter-
rupted. (If the bit is not set, the dwell time is repeated completely).
1 Reserved
2 When the bit is set, the repositioning of individual axes can be pre-
vented or delayed via the VDI interface.
3 When the bit is set, positioning axes are repositioned in the approach
block during search run via program test.
4 As 3, but after every Repos, not only during search run.
5 When the bit is set, changed feeds and spindle speeds already become
valid in the residual block, otherwise not until the following block.
6 When the bit is set, neutral axes and positioning spindles are reposi-
tioned after SERUPRO as command axes in the approach block.
7 The bit changes the behavior of the VDI-AXIN interface signal "Repos
Delay". The level of "Repos Delay" is read if REPOSA is interpreted. Axes
that are neither geo nor orientation axes are then excluded from the REPOS,
that is REPOS does NOT move these axes.
Description: Enable utilization analysis via synchronized actions.
This MD11510 $MN_IPO_MAX_LOAD sets the IPO computing time (in % of the IPO
cycle) after which the variable $AN_IPO_LOAD_LIMIT is to be set to TRUE. The
variable is reset to FALSE if the value falls below this after having once
exceeded it.
This diagnostics function is disabled if the machine data is 0.
11470 REPOS_MODE_MASK EXP, N01 K1
- Repositioning properties DWORD PowerOn
-
- - 0x8 0 0xFFFF 1/1
11510 IPO_MAX_LOAD N01, N05 -
% Max. permitted IPO load DOUBLE PowerOn
-
- - 0.00 0.0 100.0 1/1
