Siemens SINUMERIK 828D PPU Series User Manual

Pin Signal name Type Pin Signal name Type
33 DI113.7 34 DO113.7
35 DI120.0 36 DI120.1 I
37 DI120.2 38 DI120.3 I
39 Reserved 40 Reserved
Table 7-48 Assignment of connector X112
Pin Signal name Type Pin Signal name Type
1 Ground V 2 Ground V
3 DI114.0 I 4 DO114.0 O
5 DI114.1 6 DO114.1
7 DI114.2 8 DO114.2
9 DI114.3 10 DO114.3
11 DI114.4 12 DO114.4
13 DI114.5 14 DO114.5
15 DI114.6 16 DO114.6
17 DI114.7 18 DO114.7
19 DI115.0 20 DO115.0
21 DI115.1 22 DO115.1
23 DI115.2 24 DO115.2
25 DI115.3 26 DO115.3
27 DI115.4 28 DO115.4
29 DI115.5 30 DO115.5
31 DI115.6 32 DO115.6
33 DI115.7 34 DO115.7
35 DI120.4 36 DI120.5 I
37 DI120.6 38 DI120.7 I
39 Reserved 40 Reserved
Table 7-49 Assignment of connector X113
Pin Signal name Type Pin Signal name Type
1 Ground V 2 Ground V
3 DI116.0 I 4 DO116.0 O
5 DI116.1 6 DO116.1
7 DI116.2 8 DO116.2
9 DI116.3 10 DO116.3
11 DI116.4 12 DO116.4
13 DI116.5 14 DO116.5
15 DI116.6 16 DO116.6
17 DI116.7 18 DO116.7
19 DI117.0 20 DO117.0
21 DI117.1 22 DO117.1
23 DI117.2 24 DO117.2
Connectable components
7.3 MCP Interface PN
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 143
