X242 pin assignment
Pin Signal name NC variable Meaning
1 Not connected
2 Not connected
3 IN1 DIN1 $A_IN[1] Digital NC input 1
4 IN2 DIN2 $A_IN[2] Digital NC input 2
5 IN3 DIN3 $A_IN[3] Digital NC input 3
6 IN4 DIN4 $A_IN[4] Digital NC input 4
7 M4 MEXT4 Ground for pins 3...6
8 P3 P24EXT3 +24 V power supply
9 O1 DOUT1 $A_OUT[1] Digital NC output 1
10 O2 DOUT2 $A_OUT[2] Digital NC output 2
11 M3 MEXT3 Ground for pins 9, 10, 12, 13
12 O3 DOUT3 $A_OUT[3] Digital NC output 3
13 O4 DOUT4 $A_OUT[4] Digital NC output 4
14 M3 MEXT3 Ground for pins 9, 10, 12, 13
X252 pin assignment
Pin Signal name NC variable Meaning
1 AO AOUT Analog output (voltage for analog spindle)
2 AM AGND Analog ground
3 IN9 DIN9 $A_IN[9] Digital NC input 9
4 IN10 DIN10 $A_IN[10] Digital NC input 10
5 IN11 DIN11 $A_IN[11] Digital NC input 11
6 IN12 DIN12 $A_IN[12] Digital NC input 12
7 M4 MEXT4 Ground for pins 3...6
8 P3 P24EXT3 +24 V power supply
9 O9 DOUT9 $A_OUT[9] Digital NC output 9
10 O10 DOUT10 $A_OUT[10] Digital NC output 10
11 M3 MEXT3 Ground for pins 9, 10, 12, 13
12 O11 DOUT11 -- ● Without analog spindle:
Digital NC output 11
● With analog spindle:
Controller release for analog spindle
(in accordance with
MD30134 $MA_IS_UNIPOLAR_OUT
PUT)
