No. Parameter
mask
Parameter
internal
Data type Meaning
28 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Software version identification
1 = SLOT2 functions as of software
version 2.5
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
29 <_AMODE> INT Alternative mode
UNITS: Final depth Z1 (abs/inc)
0 = Compatibility
1 = Z1 (inc)
2 = Z1 (abs)
TENS: Reserved
HUNDREDS: Insertion depth for chamfering ZFS
0 = ZFS (abs)
1 = ZFS (inc)
3.25.1.9 LONGHOLE - elongated hole
Syntax
LONGHOLE(<RTP>, <RFP>, <SDIS>, <_DP>, <_DPR>, <NUM>, <LENG>, <_CPA>,
<_CPO>, <RAD>, <STA1>, <INDA>, <FFD>, <FFP1>, <MID>, <_VARI>,
<_UMODE>, <_GMODE>, <_DMODE>, <_AMODE>)
Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <_RFP> REAL Reference point of tool axis (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <_DP> REAL Long hole depth (abs)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1039
