4.3.55 G group 55: Rapid traverse with/without linear interpolation
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
RTLION 1 Rapid traverse motion with linear interpolation ON + m x
RTLIOF 2 Rapid traverse motion with linear interpolation OFF
Rapid traverse motion is achieved with single-axis in‐
terpolation.
+ m
4.3.56 G group 56: Taking into account tool wear
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
TOWSTD 1 Initial setting value for offsets in tool length + m x
TOWMCS 2 Wear values in the machine coordinate system (MCS) + m
TOWWCS 3 Wear values in the workpiece coordinate system
(WCS)
+ m
TOWBCS 4 Wear values in the basic coordinate system (BCS) + m
TOWTCS 5 Wear values in the tool coordinate system (toolholder
ref. point T at the toolholder)
+ m
TOWKCS 6 Wear values in the coordinate system of the tool head
for kinetic transformation
(differs from machine coordinate system through tool
rotation)
+ m
4.3.57 G group 57: Corner deceleration
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
FENDNORM 1 Corner deceleration OFF + m x
G62 2 Corner deceleration at inside corners when tool radius
compensation is active (G41/G42)
+ m
G621 3 Corner deceleration at all corners + m
4.3.58 G group 59: Dynamic response mode for path interpolation
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
DYNNORM 1 Standard dynamic response + m x
DYNPOS 2 Positioning mode, tapping + m
Tables
4.3 G commands
NC programming
1264 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
