No. Parameter
mask
Parameter
internal
Data type Meaning
22 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Type of feedrate: G group (G94/G95) for
surface and depth feedrate
0 = Compatibility mode
1 = G command as before cycle call.
G94/G95 same for surface and
depth feedrate
THOUSANDS:
0 = Compatibility mode: Contour
name is in <_KNAME>
1 = Contour name is programmed in
CYCLE62 and transferred to
_SC_CONT_NAME
23 <_AMODE> INT Alternative mode
UNITS: End point Z1 (<_DP>)
0 = Absolute (compatibility mode)
1 = Incremental
TENS: Units for plane infeed
0 = mm, inch
1 = Reserved
HUNDREDS: Insertion depth for chamfering (<_ZFS>)
0 = Absolute
1 = Incremental
Note
If the following transfer parameters are programmed indirectly (as parameters), the screen
form is not reset:
<_VARI>, <_RL>, <_AS1>, <_AS2>, <_UMODE>, <_GMODE>, <_DMODE>,
<_AMODE>
3.25.1.17 CYCLE76 – rectangular spigot
Syntax
CYCLE76(<_RTP>, <_RFP>, <_SDIS>, <_DP>, <_DPR>, <_LENG>, <_WID>,
<_CRAD>, <_PA>, <_PO>, <_STA>, <_MID>, <_FAL>, <_FALD>, <_FFP1>,
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1055
