No. Parameter
mask
Parameter
internal
Data type Meaning
22 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: --- Reserved
HUNDREDS: --- Reserved
THOUSANDS: --- Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
23 <_AMODE> INT Alternative mode
UNITS: Final depth (<_DP>)
0 = Absolute
1 = Incremental
TENS: Units for plane infeed (<_MIDA>)
0 = mm
1 = % of tool diameter
HUNDREDS: Insertion depth for chamfering (<_ZFS>)
0 = Absolute
1 = Incremental
THOUSANDS: Corner rounding (<_RC>)
0 = Radius
1 = Chamfer
3.25.1.21 CYCLE81 - drilling, centering
Syntax
CYCLE81(<RTP>, <RFP>, <SDIS>, <DP>, <DPR>, <DTB>, <_GMODE>,
<_DMODE>, <_AMODE>)
Parameter
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <RFP> REAL Reference point (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
Work preparation
3.25 Programming cycles externally
NC programming
1064 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
