Siemens SINUMERIK 840DE SL

G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
DYNROUGH 3 Roughing + m
DYNSEMIFIN 4 Rough finishing + m
DYNFINISH 5 Finishing + m
DYNPREC 6 Smooth finishing + m
4.3.59 G group 60: Working area limitation
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
WALCS0 1 Workpiece coordinate system working area limitation
OFF
+ m x
WALCS1 2 WCS working area limitation group 1 active + m
WALCS2 3 WCS working area limitation group 2 active + m
WALCS3 4 WCS working area limitation group 3 active + m
WALCS4 5 WCS working area limitation group 4 active + m
WALCS5 6 WCS working area limitation group 5 active + m
WALCS6 7 WCS working area limitation group 6 active + m
WALCS7 8 WCS working area limitation group 7 active + m
WALCS8 9 WCS working area limitation group 8 active + m
WALCS9 10 WCS working area limitation group 9 active + m
WALCS10 11 WCS working area limitation group 10 active + m
4.3.60 G group 61: Tool orientation smoothing
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
ORISOF 1 Tool orientation smoothing OFF + m x
ORISON 2 Tool orientation smoothing ON + m
4.3.61 G group 62: Repositioning mode for REPOS (non-modal)
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
RMBBL 1 Repositioning to start of block - s
RMIBL 2 Repositioning to interrupt point - s x
Tables
4.3 G commands
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1265
