Tool parameters Meaning
$TC_DP1 Tool type
$TC_DP2 Cutting edge position
$TC_DP3 Geometry - length 1
$TC_DP4 Geometry - length 2
$TC_DP6 Geometry - radius (cutting edge radius)
$TC_DP21 Base dimension - length 1
$TC_DP22 Base dimension - length 2
$TC_DP23 Base dimension - length 3
● Wear values corresponding to the requirements.
● Set other values to 0.
2.5.5.6 Special tools
The following tool types are available in the "Special tools" group:
700 Slotting saw
710 3D probe
711 Edge probe
712 Mono probe
713 L probe
714 Star probe
725 Calibration tool
730 Stop
731 Spindle sleeves
732 End support
Fundamentals
2.5 Tool offsets
NC programming
78 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
