4.3.14 G group 14: Workpiece measuring absolute/incremental
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G90 1 Absolute dimension + m x
G91 2 Incremental dimensions + m
4.3.15 G group 15: Feed type
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G93 1 Inverse-time feedrate rpm + m
G94 2 Linear feedrate in mm/min, inch/min + m x
G95 3 Revolutional feedrate in mm/rev, inch/rev + m
G96 4 Revolutional feedrate (as for G95) and constant cutting
rate
+ m
G97 5 Revolutional feedrate and constant spindle speed (con‐
stant cutting rate OFF)
+ m
G931 6 Feedrate specified by means of traversing time, deac‐
tivate constant path velocity
+ m
G961 7 Linear feedrate (as for G94) and constant cutting rate + m
G971 8 Linear feedrate and constant spindle speed (constant
cutting rate OFF)
+ m
G942 9 Linear feedrate and constant cutting rate or constant
spindle speed
+ m
G952 10 Revolutional feedrate and constant cutting rate or con‐
stant spindle speed
+ m
G962 11 Linear feedrate or revolutional feedrate and constant
cutting rate
+ m
G972 12 Linear feedrate or revolutional feedrate and constant
spindle speed (constant cutting rate OFF)
+ m
G973 13 Revolutional feedrate without spindle speed limitation
and constant spindle speed (G97 without LIMS for ISO
mode)
+ m
Tables
4.3 G commands
NC programming
1252 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
