No. Parameter
mask
Parameter
internal
Data type Meaning
12 F <_FFP1> REAL Machining feedrate
13 <_VARI> INT Machining type
UNITS: Machining
1 = Roughing
2 = Finishing
TENS: Machining direction
1 = Parallel to the 1st axis, in one di‐
rection
2 = Parallel to the 2nd axis, in one di‐
rection
3 = Parallel to the 1st axis, varying
direction
4 = Parallel to the 2nd axis, varying
direction
14 <_LIM> INT Limits
UNITS: Limit 1st axis negative
0 = No
1 = Yes
TENS: Limit 1st axis positive
0 = No
1 = Yes
HUNDREDS: Limit 2nd axis negative
0 = No
1 = Yes
THOUSANDS: Limit 2nd axis positive
0 = No
1 = Yes
15 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1045
