No. Parameter
mask
Parameter
internal
Data type Meaning
19 FS <_FS> REAL Chamfer width (inc) for chamfering
20 ZFS <_ZFS> REAL Insertion depth of tool tip when chamfering (see <_AMODE> HUN‐
DREDS)
21 TR <_TR> STRING[32] Reference tool name when machining residual material
22 DR <_DR> INT Reference tool D number when machining residual material
23 <_UMODE> INT Reserved
24 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Reserved
HUNDREDS: Select machining/only calculation of start
point
0 = Normal machining (no compatibil‐
ity mode needed)
1 = Normal machining
2 = Reserved
25 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Reserved
HUNDREDS: Technology mode
1 = Pocket
2 = Spigot
THOUSANDS: Machine residual material
0 = No
1 = Yes
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
HUNDRED THOUSANDS: Automatic program name
0 = No
1 = Yes
Work preparation
3.25 Programming cycles externally
NC programming
1048 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
