No. Parameter
mask
Parameter
internal
Data type Meaning
23 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Reserved
HUNDREDS: Select machining or just calculation of
start point
0 = Compatibility mode
1 = Normal machining
THOUSANDS: Dimensioning of spigot acc. to center or
corner
0 = Compatibility mode
1 = Dimensioning via center
2 = Dimensioning of corner point,
spigot +L +W
3 = Dimensioning of corner point,
spigot -L +W
4 = Dimensioning of corner point,
spigot +L -W
5 = Dimensioning of corner point,
spigot -L -W
TEN THOUSANDS: Complete machining or remachining
0 = Compatibility mode
1 = Complete machining
2 = Post machining
24 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: --- Reserved
HUNDREDS: --- Reserved
THOUSANDS: --- Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1057
