No. Parameter
mask
Parameter
internal
Data type Meaning
15 <_VARI> INT Machining type
UNITS: Machining
1 = Roughing to final machining al‐
lowance
2 = Finishing (allowance X/Y/Z=0)
5 = Chamfering
16 ∅1 <_AP1> REAL Diameter of blank spigot
17 FS <_FS> REAL Chamfer width (inc)
18 ZFS <_ZFS> REAL Insertion depth (tool tip) on chamfering (abs/inc), see <_AMODE>
19 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Reserved
HUNDREDS: Select machining/only calculation of start
point
0 = Compatibility mode
1 = Normal machining
THOUSANDS: Reserved
TEN THOUSANDS: Complete machining/remachining
0 = Compatibility mode
(process <_AP1> as before)
1 = Complete machining
2 = Post machining
20 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: --- Reserved
HUNDREDS: --- Reserved
THOUSANDS: --- Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1059
