No. Parameter
mask
Parameter
internal
Data type Meaning
29 <_AMODE> INT Alternative mode
UNITS: Thread length in Z
0 = Absolute
1 = Incremental
TENS: Thread length in X
0 = Absolute, value of transverse ax‐
is in the diameter
1 = Incremental, value of transverse
axis in the radius
2 = α
HUNDREDS: Calculation of approach/run-in
path <_APP>
0 = Thread run-in <_APP>
1 = Thread run-in = thread run-out
<_APP> = -<_ROP>
2 = Specify thread run-in path
<_APP> = -<_APP>
THOUSANDS: Select infeed slope as angle or width
0 = Infeed angle <_IANG>
1 = Infeed slope <_IFLANK>
TEN THOUSANDS: Single/multiple thread
0 = Single thread (with starting angle
offset <_NSP>)
1 = Multiple
HUNDRED THOUSANDS: Starting thread <_GST>
0 = Full machining
1 = Start machining from this thread
2 = Only machine this thread
ONE MILLION: Sag compensation for longitudinal thread
0 = Segment height, crowned thread
XS
1 = Radius, crowned thread RS
30 XS/RS <_S_XRS> REAL Sag compensation for longitudinal thread in conjunction
with <_AMODE>: ONE MILLION
Note
1)
Parameters <_PITM>, <_PTAB> and <_PTABA> are only used for thread selection in the
screen form thread tables.
The thread tables cannot be accessed via cycle definition in the cycle run time.
