No. Parameter
mask
Parameter
internal
Data type Meaning
13 <_PITA> INT Pitch unit (evaluation of <PIT> and <MPIT>)
0 = Pitch in mm - evalua‐
tion<MPIT>/
<PIT>
1 = Pitch in mm - evaluation<PIT>
2 = Pitch in TPI - evaluation of
<PIT>
(threads per inch)
3 = Pitch in inches - evaluation<PIT>
4 = MODULUS - evaluation<PIT>
14 <_TECHNO> INT Technology
1)
UNITS: Exact stop response
0 = Exact stop response active as before cy‐
cle call
1 = Exact stop G601
2 = Exact stop G602
3 = Exact stop G603
TENS: Feedforward control
0 = With/without feedforward control active
as before cycle call
1 = With feedforward control FFWON
2 = Without feedforward control FFWOF
15 <_PITM> STRING[15] String as marker for pitch input
2)
16 <_PTAB> STRING[5] String for thread table ("", "ISO", "BSW", "BSP", "UNC")
2)
17 <_PTABA> STRING[20] String for selection from thread table (e.g. "M 10", "M 12", ...)
2)
18 <_GMODE> INT Reserved
Work preparation
3.25 Programming cycles externally
NC programming
1112 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
