No. Parameter
mask
Parameter
internal
Data type Meaning
29 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Re‐
serve
d
TENS: Re‐
serve
d
HUNDREDS: Select machining/only calculation of start
point
0 = Normal machining (no compatibil‐
ity mode needed)
1 = Normal machining
2 = Calculate start point - no machin‐
ing (only for call from ShopMill/
ShopTurn)
THOUSANDS: Limit
0 = No
1 = Yes
TEN THOUSANDS: Enter limit 1 X
0 = No
1 = Yes
HUNDRED THOUSANDS: Enter limit 2 X
0 = No
1 = Yes
ONE MILLION: Enter limit 1 Z
0 = No
1 = Yes
TEN MILLIONS: Enter limit 2 Z
0 = No
1 = Yes
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1127
