No. Screen pa‐
rameters
Cycle pa‐
rameters
Meaning
Log Values: UNITS: Select protocol off / on / last measurement
0 = Log OFF
1 = Log ON
2 = Log last measurement
Log type TENS: Select log type
0 = Standard log
1 = User log (can be freely defined)
Log format HUNDREDS: Select log format
0 = Text format
1 = Table format (for import to Excel)
Log data THOUSANDS: Rewrite or attach selection
0 = New
1 = Attach
Log
archive
TEN THOUSANDS: Select log archive
0 = As part program
1 = Directory
3 S_PATH Path for the log file corresponding to the log archive selection
(complete path name or only file name, e.g.:
"//NC:/WKS.DIR/NAME.WPD or "MESSPROTOKOLL.TXT"
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1195
