Address iden‐
tifier (default
setting)
Address type Modal/
non-
modal
G90/
G91
IC AC DC,
ACN,
ACP
CIC,
CAC,
CDC,
CACN,
CACP
PR,
PM
QU Max.
num‐
ber
Data type of the
assigned value
TOFFR Tool radius off‐
set
m REAL
TOFFLR Simultaneous
tool length offset
and tool radius
offset
m REAL
1)
Absolute end points: Modal, incremental end points: non-modal, otherwise modal/non-modal depending on the G command
that determines the syntax.
2)
As circle center points, IPO parameters act incrementally. They can be programmed in absolute mode with AC. The address
modification is ignored when the parameters have other meanings (e.g. thread lead).
Tables
4.2 Addresses
NC programming
1246 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
