Program code Comment
START(LOADER) ; Start of channel 2
START using local "channel names", user variables and parameterized channel names
Program code Comment
DEF INT chanNo1 ; Definition of user variable for channel 1
DEF INT chanNo2 ; Definition of user variable for channel 2
chanNo1 = CHAN_1 ; Assignment of parameterized channel name channel 1
chanNo2 = CHAN_2 ; Assignment of parameterized channel name channel 2
...
START(ChanNo1) ; Start of channel 1
START(ChanNo2) ; Start of channel 2
INIT command with absolute path specification
Selection of program /_N_MPF_DIR/_N_ABSPAN1_MPF in channel 2.
Program code
INIT(2,"/_N_WCS_DIR/_N_SHAFT1_WPD/_N_CUT1_MPF")
INIT command with program name
Selection of the program with the name "MYPROG". The control searches for the program
using the search path.
Program code
INIT(2,"MYPROG")
Work preparation
3.1 Flexible NC programming
NC programming
484 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
