<!-- **** For all tool types *** -->
<TOOLTYPE_ALL>
<!-- **** Display tool location type *** -->
<Item value="ToolPlaceSpec" type="QString" />
</TOOLTYPE_ALL>
<!-- **** For all multitools *** -->
<TOOLTYPE_9997>
<!-- **** Display for all multitool location types *** -->
<Item value="MultiToolPlaceSpec" type="QString" />
</TOOLTYPE_9997>
</COLUMN8>
</INSERT_COLUMN>
</SlTmToolmagazinForm>
</LISTCONFIGURATION>
Example 2: Configuring the magazine list - "Oversized tool" column is deleted
Note
The columns of the list configuration cannot be taken from the display in the user interface in
all cases because some columns are automatically inserted and therefore not included in the
count of the configuration.
<LISTCONFIGURATION>
<!-- **** Magazine list *** -->
<SlTmToolmagazinForm>
<!-- **** Delete column 7 *** -->
<DELETE_COLUMN>
<COLUMN7 />
</DELETE_COLUMN>
</SlTmToolmagazinForm>
</LISTCONFIGURATION>
Example 3: Enabling the OEM tool data list
<SlTmTooloemForm>
<Enabled value="true" type="bool" />
</SlTmTooloemForm>
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
180 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
