See also
Please refer to the following section for the procedure to create language-dependent text:
Creating OEM texts (Page 228)
12.2.15 Configuring the "Assign Tooltips for Multitool Locations" window
<MULTITOOLPLACETOOLTIPCONFIGURATION> tag
You will find the entries for assigning tooltips in the tag
<MULTITOOLPLACETOOLTIPCONFIGURATION>. This is particularly useful if all the
multitools used on a turning machine have two locations and a fixed assignment between
multitool locations and the main spindle or the counter spindle exists, for example,
location 1 - main spindle location 2 - counter spindle. In this case, the tooltip for location 1
could be "Tool Holder for Main Spindle."
Entries Meaning
PLACE_XXX XXX stands for the multitool location number.
Tooltip Text identifier of the magazine location.
Example
<MULTITOOLPLACETOOLTIPCONFIGURATION>
<PLACE_1>
<ToolTip value="TM_HOLDER_OF_MAIN_SPINDLE" type="QString" />
</PLACE_1>
<PLACE_2>
<ToolTip value="TM_HOLDER_OF_COUNTER_SPINDLE" type="QString" />
</PLACE_2>
</MULTITOOLPLACETOOLTIPCONFIGURATION>
See also
Please refer to the following section for the procedure to create language-dependent text:
Creating OEM texts (Page 228)
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
210 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
