Tag identifier Meaning
TYPEDEF Continued Some predefined functions expect variables of structure type RECT, POINT, or SIZE as
the call parameter. These structures are defined in the file struct_def.xml.
RECT:
<typedef name="StructRect" type="struct" >
<element name="left" type="int">0</element>
<element name="top" type="int">0</element>
<element name="right" type="int">0</element>
<element name="bottom" type="int">0</element>
</typedef>
POINT:
<typedef name="StructPoint" type="struct" >
<element name="x" type="int">0</element>
<element name="y" type="int">0</element>
</typedef>
SIZE:
<typedef name="StructSize" type="struct" >
<element name="width" type="int">0</element>
<element name="height" type="int">0</element>
</typedef>
UNLOCK_OPERAT‐
ING_AREA
Withdrawal of operating area switchover lock
Syntax:
<UNLOCK_OPERATING_AREA />
WAITING The tag waits for the component to undergo a hot restart after an NC or drive reset.
Attributes:
● WAITINGFORNC = "TRUE" - the system waits for the NC to restart
● WAITINGFORDRIVE = "TRUE" - the system waits for the drives to restart
Syntax:
<WAITING WAITINGFORNC = "TRUE"/>
Example:
...
<CONTROL_RESET resetnc = "true" resetdrive = "true"/>
<WAITING waitingfornc = "true" waitingfordrive = "true" />
...
Generating user dialogs
1.7 XML identifier
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 41
