Validity
The following description applies to the following components:
Designation Features Article number
HT 10 Enabling button, emergency stop button, override
rotary switch
6FC5403-0AA21-0AA1
HT 10H Enabling button, emergency stop button, override
rotary switch, handwheel
6FC5403-0AA21-1AA1
Characteristics
Device front:
• Pixel-graphics 10.1" TFT color display
– 1280 x 800 (WXGA) color TFT
– LED backlight
• Multi-touch operation and gesture control via touch screen, can also be actuated when
operators are wearing gloves.
• Touch keys: Keys on predened, reserved area of the screen
• Unlit emergency stop button (2-channel)
• 7 mechanical function keys with colored replaceable caps, tactile feedback and LED
checkback signal above each key
• Easy hot swapping during operation (hot plug and play) possible without tripping the
emergency stop in combination with the "SIMATIC PN advanced" connection box and
without an additional, manual actuating element / keyswitch
• Rotary override switch (19 positions)
• Handwheel (only with 6FC5403-0AA21-1AA1)
Device rear:
• Power supply (+24 V)
• 1 enabling button (2-channel, 3-stage)
• Cover with option of installing a connecting cable (can be ordered separately) to the
connection box/connection module (24 V)
• Customer interfaces:
– HT 10 connecting cable to connection box / connection module
– USB interface 3.0 (with dummy plug)
Optional:
Wall holder (accessory): The HT 10 can be kept safely and operated in a stationary manner in the
wall holder.
Description
2.1 Characteristics
Handheld Terminal HT 10
14 Equipment Manual, 09/2020, A5E47430965B AA
