5.5.2 Diagnostics options during booting
Diagnostics while booting supplementary conditions
In the following supplementary conditions, the diagnostics window is displayed and booting of
the TCU is interrupted:
• When the <1 / F1> function is selected during booting
• When a warning message is displayed
• When a fault occurs
You can select functions <1 / F1> to <8 / F8> mentioned below by tapping on the Panel.
Alternatively, you can do this via the corresponding function keys of a connected USB
keyboard.
Using the <1 / F1> function
7hin Client Bootloader
Boot Progress
BIOS Version
MAC Address
Hardware-ID
Network link
Boot from USB
IP Address
Netmask
DHCP Server
Boot Server
Image Metadata
Image Version
Linux Image (linux.bin)
Image Kind
Booting
<1/F1> protocol <2/F2> Readme_OSS <7/F7> continue <8/F8> reboot
V05.00.45.00
V15.00.00.00
08:06:00:F1:F7:F8
7.9.2.0
1000MB, full duplex
no device found
192.168.214.14
255.255.255.0
192.168.214.1
192.168.214.1
71 bytes
V05.00.46.00
3295436 bytes
from boot server
ready
Key / text Meaning
F1 protocol Display detailed information
F2 Readme_OSS Details of the Open Source licenses
F7 continue Continue booting of the TCU
F8 reboot Restart the TCU
Commissioning
5.5 Troubleshooting
Handheld Terminal HT 10
74 Equipment Manual, 09/2020, A5E47430965B AA
