4.4.4 Interface assignment
Location of the interfaces
① Fast connector
② Terminal strip 1
③ Terminal strip 2
Fast Connector, 4-pin
The connection box contains two fast connectors for connecting the PROFINET data cables. The
󹪝gure below illustrates the assignment of the fast connector:
Connecting
4.4 SIMATIC connection box
Handheld Terminal HT 10
36 Equipment Manual, 09/2020, A5E47430965B AA
