<source>SK_USERKEY1</source>
<comment></comment>
<translation>U1</translation>
<remark>User key 1</remark>
<chars>10</chars>
<lines>2</lines>
<languageIndependent>true</languageIndependent>
</message>
<message>
<source>SK_USERKEY2</source>
<comment></comment>
<translation>U2</translation>
<remark>User key 2</remark>
<chars>10</chars>
<lines>2</lines>
<languageIndependent>true</languageIndependent>
</message>
<message>
.....
</message>
</context>
</TS>
5.3 Con󹪝guring the function display at user-speci󹪝c keys (U keys)
Function
Active functions can be displayed at the con󹪝gurable user keys via the PLC. For instance, small
LEDs can be emulated on the softkeys.
You con󹪝gure the function in the "slckcpf.ini" 󹪝le.
Interface signals
The PLC bits are in the output image of the PLC/HT 10 interface and are analogous to those in the
input image.
Signals to the MCP1 (or MCP2)
Interface PLC → HT 10
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
AB n + 1 U4 U3 U2 U1
AB n + 4 U9 U10 U11 U12 U13 U14 U15 U16
AB n + 5 U8 U7 U6 U5
Commissioning
5.3 Con󹪝guring the function display at user-speci󹪝c keys (U keys)
Handheld Terminal HT 10
Equipment Manual, 09/2020, A5E47430965B AA 67
