Language code in le names "xxx"
Language Language code
German deu
English eng
French fra
Spanish esp
Italian ita
Chinese chs
Creating key labeling
Tag Meaning
source Designation for the user softkey. "SK_USERKEY1" to "SK_USERKEY16" are possible,
whereby the names may not be changed.
comment User-specic description of the key assignment.
translation Text that should be shown on the key.
• A maximum of 10 characters are possible per line.
• 2-line labeling is possible, whereby the line break is set using "%n".
remark Remark for key assignment.
chars Number of characters. A maximum of 10 characters per line are possible.
lines Number of lines. 2 lines are possible.
Procedure
1. You can copy the sample le "oem_slck_deu.ts" from the following folder: /siemens/
sinumerik/hmi/template/lng.
2. Store or create the le in the /oem/sinumerik/hmi/lng or
/user/sinumerik/hmi/lng directory.
3. Give the le a name, e.g. for German texts: "slck_deu.ts".
If you wish to create the key labeling for additional languages, then a separate le must be
created for each language. Save the le with the appropriate language code in the le name.
To do this, use the language codes specied above.
4. Open the le and in the <message> and </message> area, dene the key labeling.
5. Restart the HMI.
In order that the key labeling is displayed during the program runtime, the le must be
converted into a binary format. This conversion is only executed when the HMI powers up.
Example of a key label
<!DOCTYPE TS><TS>
<context>
<name>SlCkDialog</name
<message>
Commissioning
5.2 Conguring user-specic key labeling
Handheld Terminal HT 10
66 Equipment Manual, 09/2020, A5E47430965B AA
