4.5.4 Installing the terminating connector
Procedure
Note
If you never remove the HT 10 from the connection module, it is not necessary to attach the
terminating connector.
1. Unscrew the fastening nut ①.

2. Attach the bracket ① for the terminating connector ②.


3. Tighten the fastening nut and insert the terminating connector into the bracket.
Connecting
4.5 PN Basic connection module
Handheld Terminal HT 10
Equipment Manual, 09/2020, A5E47430965B AA 59
