Pin Signal name Signal type Signal
type
9 STOP -23 EMERGENCY STOP circuit 1 K
10 STOP -24 EMERGENCY STOP circuit 1 K
11 P24 +24 V power supply VI
12 M24 External ground VI
4.2.2 USB interfaces
X5: USB interface
The USB interface conforms to the specication for USB 3.0 Hi-Speed type A.
Connector designation: X5
Connector type: Type A socket
Current carrying capaci‐
ty
0.9 A
Max. cable length 5 m
Pin Signal name Signal type Signal
type
1 Shield Shield
2 +5 V Power supply for external devices VO
3 USB-DN USB data - channel 1 B
4 USB-DP USB data + channel 1 B
5 0 V Ground VO
6 Shield Shield
NOTICE
Damage to the connector caused by missing protective cap
Replace the USB connector if its protective cap is torn, because the connector is no longer
protected against dirt.
NOTICE
Damage to the inserted USB FlashDrive should the HT 10 fall to the ground
An inserted USB FlashDrive can be damaged or broken o if the device falls.
Connecting
4.2 Pin assignment of the interfaces
Handheld Terminal HT 10
Equipment Manual, 09/2020, A5E47430965B AA 27
